Bremsscheibe
Dynamic Friction Company : 600-47006
Artikel-Nr.: DFC600-47006
- Bolt Hole Diameter: 1/2-20 mm
- Bolt Hole Quantity: 5 EA
- Center Hole Diameter: 77.7 MM
- Directional or Non-Directional Brake Surface: Non-Directional
- Discard Thickness: 24.51 MM
- Hat Finish: Rust Preventative
- Height: 118.1 mm
- Inside Diameter: 77.7 mm
- Nominal Thickness: 26.29 MM
- Outside Diameter: 302 MM
- Overall Height: 118.1 MM
- Rust Resistant Coating: Yes
- Solid Or Vented Type Rotor: Vented
- Stud/Lug Hole Circle Diameter: 127 MM
- Stud/Lug Hole Quantity: 5
- Surface Type: Smooth
- EISD5028: Replaced
- RAY5028: Replaced
