Stoffbuchse
National Seal : RNT4503N
Artikel-Nr.: NAS4503N
- Flanged Outside Diameter: 3.270 IN
- Flanged Outside Diameter: 83.058 MM
- Helix Type: Bi-Directional Lip Design
- Housing Bore: 2.750 IN
- Housing Bore: 69.850 MM
- Inside Diameter: 1.886 IN
- Inside Diameter: 47.900 MM
- Material: Polyacrylate
- Outside Diameter: 2.765 IN
- Outside Diameter: 70.230 MM
- Overall Width with Side Lip: 1.375 IN
- Overall Width with Side Lip: 34.930 MM
- Part Description: Oil Seal
- Sealing Material: Polyacrylate
- Series: 4000
- Shaft Diameter: 1.886 IN
- Shaft Diameter: 47.900 MM
- Thickness: 0.469 IN
- Thickness: 11.900 MM
- Type: #
- Unit of Dimension: Inch
- Width: 0.469 IN
- Width: 11.900 MM
- 1300044006:
- 1300-044-006:
- 15580329:
- 15662465:
- 18507:
- 18687:
- 1900-044-030:
- 24261932:
- 2L14-7B215AA:
- 2L14-7B215-CA:
- 2L1Z-7B215-A:
- 3363012:
- 4503N:
- 48132:
- 68089735AA:
- 68402279AA:
- 88984500:
- 89059495:
- E7TZ-7052A:
- E8TZ7B215A:
- F4TZ7B215B:
